ProSort 400 Elite Series ProSort 400 Elite Series
ProSort 400 SeriesHytrol's ProSort 400 Family of sorters is specifically designed to handle high-speed applications where product diverting needs to be both positive and gentle. The ProSort 421 is designed to sort products at a 22 degree angle where higher speeds are required and close divert centers are not so critical, speeds of 700 FPM are possible. The ProSort 431 is designed to sort products at a 30 degree angle where close divert centers are required and speeds of 350 FPM are possible. The ProSort Elite series is solely offered as single sided, diverting positively from left or right-hand sides.


  • High sort rates
  • Minimum gap anodized aluminum slat
  • High efficiency gearmotor
  • 2 optional divert switches
  • Wrap-around shoe design
  • Integrated induction conveyor
  • ProLogix & ProLogix Plus controls
  • Sealed lubricated carrying chain
  • Capable of 700 FPM
  • Plug-N-Go wiring
  • Continuous polyurethane bearing track




Optional divert angles 22? and 30?

  • 2 high-speed divert switches
    • Pneumatic, using RPT technology
    • Electric, using Servo technology
  • Rubber isolators for quietness and easily removable for maintenance
  • Quick change design for both options which minimizes sorter down time.


  • PLC based controls package that controls the ProSort 400 Elite series from induction point, through divert confirmation, including sorter diagnostics.
  • Plug-N-Go? wiring for simple, quick, trouble-free installation.
  • Out of shoe position detection.
  • With purchase of controls package the Elite series receives a 3 year warranty.


  • Anodized aluminum slate design.
    • Provides product support and full coverage
    • Minimal gaps
  • Divert Shoes
    • Low friction molded shoe with high friction pusher face
    • Steel guide pin for switching
    • Ball bearing cam follower for diverting
    • Wrap-around design
    • Jam resistant shoe design for tight spacing resulting in increased carton rate
    • Designed for ease of replacement
  • Carrying Chain
    • No. 100 pre-lubricated o-ring roller chain equipped with precision bearings and extended pins
    • Run on a continuous polyurethane bearing track for low horsepower requirements, high speed and long life


Shaft mounted gearmotor, mounted at discharge end on the opposite side from diverts

  • High efficiency gearmotor
  • 230/460V-3Ph. 60Hz
  • Keyless design
  • Variable Speed Controller (VFD), which helps with flexibility to meet current demand.
  • Capable of lengths up to 700 ft.


Belt conveyor slave driven from sorter at same speed as sorter

  • Consistency in feeding sorter
  • Accurate product induction
For systems requiring dual-sided sorting, ProSort 422 & ProSort 432 are offered.
